Smart Pole Z222
Smart Pole Z222
Modular Square‑profile Steel Smart Light Pole, top‑mounted dual‑wing LED lamp, reserved interfaces for surveillance camera, outdoor LCD display and environment sensor. Multi‑functional integrated smart‑city pole for municipal roads, parks and commercial districts.
Product Overview
This square modular smart light pole is constructed from high‑strength sectional‑spliced steel profile. Its square split‑type structure ensures outstanding structural rigidity and wind resistance, while the modular splicing design simplifies on‑site assembly, inspection and module replacement work.
It is equipped with a top dual‑wing LED street‑light fixture to provide main road lighting. Standard mounting positions are pre‑reserved for a complete set of smart peripherals: security surveillance camera, high‑brightness waterproof outdoor LCD information screen, environmental monitoring sensor, and bottom interactive terminal. This all‑in‑one pole integrates road lighting, public security monitoring, information release and environmental data collection, acting as a comprehensive hardware carrier for smart‑city infrastructure upgrade.
Main Technical Parameters
表格
| Item | Specification |
|---|---|
| Pole Material | High‑quality structural steel, square modular split profile (Q235B / Q355B optional) |
| Available Height | 6m / 8m / 10m / 12m (Customizable height) |
| Surface Treatment | Hot‑dip galvanized + electrostatic powder coating, UV‑resistant, anti‑corrosion, all‑weather durability |
| Lighting Unit | Top dual‑wing integrated LED lamp, single‑side power:30W‑150W customizable |
| LCD Screen | Waterproof high‑brightness outdoor display, IP65 dust‑proof & waterproof |
| Camera Bracket | Pre‑installed bracket for IP surveillance camera |
| Environment Sensor | Optional module for temperature, humidity, noise, air‑quality monitoring |
| Protection Rating | Pole body: IP54; Electronic modules: IP65 |
| Wind‑Resistance Level | ≥ Grade 12 wind‑load resistance |
| Operating Temperature | -35℃ ~ +60℃ |
| Standard Color | Silver‑grey; Custom RAL color available |
Core Functions
- Road Lighting: Top dual‑wing LED lamp head, uniform illumination, supports timing switch and dimming control
- Video Surveillance: Special reserved bracket for monitoring camera, suitable for road safety and traffic management
- Information Release: Outdoor high‑brightness LCD screen, used for public notices, traffic alerts and information advertising
- Environmental Monitoring: Real‑time collection of noise, temperature, humidity, PM2.5 and other environmental data
- Human‑machine Interaction: Interactive module reserved at the pole base, supporting access‑control, emergency call functions
- Expandable Interfaces: Pre‑drilled wiring holes and mounting points for 5G antenna, Wi‑Fi, EV charging‑pile modules
Packaging & Shipment
- Pole segments wrapped by bubble film, reinforced with wooden frame for sea transportation
- Lamp head, screen bracket and other accessories are individually packed in cartons
- Anti‑collision loading scheme to avoid scratches, deformation during container shipment
After‑sales & Warranty Terms
- Warranty: 5‑year warranty for the steel pole body; 2‑year warranty for electronic components (lamp, screen, sensor, camera bracket). Damage caused by human operation, lightning strike and force majeure is excluded.
- Technical Documents: Complete assembly drawings, installation manual and remote online technical guidance are provided.
- Spare‑part Supply: Original spare parts are available at factory cost after warranty expiration.
- Customization Service: OEM & ODM are acceptable, including pole height, surface color, module layout and functional configuration.
