Smart Pole Z221
Smart Pole Z221
Modular Multi‑sided Steel Smart Light Pole, dual‑arm LED street light, with reserved installation positions for surveillance camera, outdoor LCD display and environmental sensor. Versatile integrated smart‑city infrastructure for municipal roads, scenic spots and commercial zones.
Product Overview
This multi‑faceted modular smart light pole adopts a segmented, splice‑on steel pole body with vertical‑rib structural design. The special polygon profile greatly improves overall structural strength and wind‑resistance capacity. The split‑assembly structure simplifies on‑site installation, inspection and component replacement work.
Equipped with double curved lamp arms for primary road lighting, the pole reserves standardized mounting interfaces for a full suite of smart modules: security camera, high‑brightness outdoor LCD information screen, environmental monitoring sensor, and bottom interactive operation terminal. It unifies lighting, public security monitoring, information publishing and environmental data collection on one single pole, which is an ideal multi‑functional hardware carrier for smart‑city construction.
Main Technical Parameters
表格
| Item | Specification |
|---|---|
| Pole Material | High‑quality structural steel, multi‑sided ribbed modular profile (Q235B / Q355B optional) |
| Available Height | 6m / 8m / 10m / 12m (Custom‑made height acceptable) |
| Surface Treatment | Hot‑dip galvanized + electrostatic powder coating, UV‑resistant, anti‑corrosion, weatherproof |
| Lighting Unit | Dual curved LED lamp arms, single lamp power 30W‑150W customizable |
| LCD Screen | Waterproof high‑brightness outdoor display, IP65 dust‑proof & water‑proof |
| Camera Bracket | Pre‑installed bracket for IP surveillance camera |
| Environment Sensor | Optional module for temperature, humidity, noise, air quality monitoring |
| Protection Rating | Pole body: IP54; Electronic accessories: IP65 |
| Wind‑Resistance Level | ≥ Grade 12 wind load capacity |
| Operating Temperature | -35℃ ~ +60℃ |
| Standard Color | Silver‑grey; Custom RAL colors are supported |
Core Functions
- Road Lighting：Two curved lamp‑arm configuration, even light distribution, supports timing switch and dimming control
- Video Surveillance：Dedicated mounting bracket for monitoring camera, suitable for road safety and traffic management
- Information Release：Outdoor high‑brightness LCD screen, can broadcast public notices, traffic alerts and commercial advertisements
- Environmental Monitoring：Real‑time acquisition of ambient indicators including noise, temperature, humidity, PM2.5
- Human‑machine Interaction：Reserved interactive module at pole base for access control, emergency call and other functions
- Expandable Interfaces：Pre‑reserved wiring holes and installation points for 5G base station, public Wi‑Fi, charging pile modules
Packaging & Shipment
- Pole sections wrapped with bubble film, reinforced by wooden frame for ocean transportation
- Lamp arms, screen brackets and other spare parts are separately packed in cartons
- Professional anti‑collision loading scheme to prevent scratch and deformation during container shipment
After‑sales & Warranty Terms
- Warranty：5‑year warranty for the steel pole body; 2‑year warranty for electronic modules (lamp, screen, sensor, camera bracket). Excludes damage caused by human error, lightning strike and force majeure.
- Technical Documents：Complete installation drawings, assembly manual and remote online technical guidance are provided.
- Spare‑part Supply：Factory‑cost original spare parts available after the warranty period expires.
- Customization Service：ODM & OEM are welcomed, including pole height, surface color, module layout and functional configuration.
